24 WIDE LEVEL DISC HARROW / SESAME SEEDER
Sesame seeder machine is produced as 24-30 discs.
It is cultivating the soil and sowing sesame seeds in high efficiency in case of grain hopper is added.
It is pulling type machine and it is easy to put into road position for easy transport to the land.
24 wide level disc harrow discs are mounted on independent gangs and this provides having perfect level of soil and in the same time this makes a perfect depth penetration into the soil.
Working width is 410-510cm with the 17,5cm disc between spaces.
It is especially usefull for sesame seed sowing with high standards.
Technical
|
Model
|
Number of Rows
|
Working Width
|
Disc Qnty.
|
Seed Capacity
|
Weight
|
Length
|
Disc Space
|
Necessary Power
|
| GSU-24 | 24 Rows | 4100 mm | 24 | 430 lt | 1420 kg | 600 cm | 17,5 cm | 70-100 hp |
| GSU-30 | 30 Rows | 5100 mm | 30 | 530 lt | 1700 kg | 700 cm | 17,5 cm | 80-120 hp |
